New 2025 Phaeton 40 IH Motor Home Class A - Diesel

* The images displayed may represent all Phaeton models

Shop Phaeton 40 IH For Sale

Previous Inventory Unit
Next Inventory Unit

Phaeton 40 IH Description

Tiffin Motorhomes Phaeton Class A diesel motorhome 40 IH highlights:

  • Booth Dinette-Sleeper
  • Two Sofa Beds
  • Convection Microwave with Air Fryer
  • Bath and a Half
  • Exterior TV
  • King Bed Slide



You will feel right at home in this coach with a master suite and king bed slide, mounted TV, laundry hamper, and stacked drawers. You all have quick access to the full rear bathroom. The bathroom not only has a dual sink vanity with a tri-view mirror for two to get ready at once, but also a shower with a seat and a large closet with an area next to it prepped to add an optional washer and dryer. The chef can prepare their best meals either indoors with the countertop extension and cooktop with convection microwave or outside if you add the optional outdoor grill. You can even watch the big game outside with the exterior TV with a sound bar!



Each one of these Tiffin Motorhomes Phaeton Class A diesel motorhomes offer high-end elegance at every turn! A PowerGlide XC raised rail rear engine diesel chassis will give you a smooth ride for every mile, and each coach comes with a Cummins L9 450 HP engine to power your journeys. There is a 10.0 kW Onan Quiet Diesel generator, three 15k BTU A/C units, and a Firefly integrations Eclipse module to keep you connected wherever you go. Outside, you'll appreciate the custom rock guard to protect your unit, along with full-body paint with four layers of clear coat and high-performance protection film on the front cap and select areas. A Girard power awning with LED lights also comes standard plus a fiberglass reinforced plastic basement floor, an exterior TV, and more. A few new features you are sure to enjoy are the standard exterior ladder, matte finish tile floor option, new Generation 12 paint schemes, Starlink roof prep, and more!

Phaeton 40 IH Specifications

Sleeps 7
Slides 4
Length 41 ft 4 in
Ext Width 8 ft 5 in
Ext Height 13 ft 3 in
Int Height 6 ft 11 in
Interior Color Capri, Tide Pool, Stallion
Exterior Color Gen 10, Gen 11; Bordeaux, Waterfall, Frosted Granite, Nasa, White Mahogany. Midnight Blue Edition
Hitch Weight 10000 lbs
GVWR 39660 lbs
Fresh Water Capacity 100 gals
Grey Water Capacity 100 gals
Black Water Capacity 55 gals
Tire Size 295/80R22.5
Furnace BTU 60000 btu
Generator 10.0kW Onan Quiet Diesel
Fuel Type Diesel
Engine Cummins L9
Chassis Freightliner PowerGlide XC Raised Rail Rear
Horsepower 450 hp
Fuel Capacity 100 gals
Wheelbase 266 in
Available Beds King
Torque 1250 ft-lb
Refrigerator Type Stainless Steel Residential with French Doors and Bottom Freezer
Refrigerator Size 25 cu ft
Convection Cooking Yes
Cooktop Burners 2
Shower Size 31.75" x 40"
Number of Awnings 2
Axle Weight Front 15660 lbs
Axle Weight Rear 24000 lbs
LP Tank Capacity 35.7 gals
Water Heater Type Truma AquaGo Comfort Instant
AC BTU 45000 btu
Basement Storage 232 cu. ft.
TV Info LR TV, BR Mounted TV, Ext. TV
Awning Info Girard Power Patio and Window
Washer/Dryer Available Yes
Gross Combined Weight 49660 lbs
Shower Type Shower w/Seat
Electrical Service 50 amp
