New 2025 Compass AWD 24KB Motor Home Class B+

* The images displayed may represent all Compass AWD models

Shop Compass AWD 24KB For Sale

Previous Inventory Unit
Next Inventory Unit

Compass AWD 24KB Description

Thor Motor Coach Compass AWD Class B+ motorhome 24KB highlights:

  • Two Twin Beds with King Conversion
  • Skylight Above Cab
  • Jack-Knife Slide
  • Convection Microwave with Air Fryer



The perfect coach for two whether you are a couple or not! This Compass AWD model features a set of twin beds that can easily convert to a king bed if you like.  Enjoy the added space thanks to a slide out jack-knife sofa with a removable pedestal table. This table is handy for dining when you are stopped. You will appreciate the kitchen amenities for light meals and snacks while on the road, plus the onboard bath offers a 27" x 27" radius shower, toilet, and sink which is convenient as well. There are also two 32" Smart TVs in this coach, one over the side entry opposite the seating in front, and one back in the sleeping area at the foot of the roadside twin bed.  A built-in skylight offers the ability to stargaze in the front of the coach on a clear night.



The Thor Motor Coach Compass AWD Class B+ gas motorhome is small but mighty! It includes all-wheel drive, and it is built upon a Ford Transit chassis, 3.5L V6 Eco Boost turbo gas engine, and Ford ten-speed automatic overdrive transmission. The Ford safety features provide excellent care while driving, and you can stay connected to your Compass AWD with the FordPass Connect. The power patio awning with LED lights can be moved out into position with just one touch on your cell phone thanks to the Rapid Camp+ multiplex control system. You will have a 100W solar panel with controller, a 15,000 BTU air conditioner, a Winegard ConnecT 2.0 Wi-Fi/4G/TV antenna, and a tankless water heater as some of the top electrical and plumbing features.





Compass AWD 24KB Specifications

Sleeps 2
Slides 1
Length 25 ft 10 in
Ext Width 7 ft 6 in
Ext Height 11 ft
Int Height 6 ft 8 in
Interior Color London Fog, Seapearl, Charcoal Matrix, Travertine 3
Exterior Color HD-Max Standard; Dress Blues, Black Ice. Full-Body Paint Options; Brilliant Carbon, River Ranch, Seashell Grey
Hitch Weight 5000 lbs
GVWR 11000 lbs
Fresh Water Capacity 31 gals
Grey Water Capacity 27 gals
Black Water Capacity 20 gals
Furnace BTU 19000 btu
Generator 4.0 kW Gas
Fuel Type Gasoline
Engine 3.5L V6 EcoBoost Turbo
Chassis Ford Transit
Horsepower 310 hp
Fuel Capacity 25 gals
Wheelbase 178 in
Available Beds Twins Convert to King
Torque 400 ft-lb
Refrigerator Type 12V Dual Door
Convection Cooking Yes
Cooktop Burners 2
Shower Size 27" x 27"
Number of Awnings 1
LP Tank Capacity 40 lbs
Water Heater Type Tankless
AC BTU 15000 btu
Basement Storage 45.4 cu. ft.
TV Info LR 32" Smart TV, BR 32" Smart TV
Awning Info 16' 6" Power w/Integrated LED Lighting
Gross Combined Weight 15000 lbs
Shower Type Radius
Electrical Service 30 amp
