New 2025 Melbourne 24L Motor Home Class C - Diesel
Get answers to your questions about this RV
Shop Melbourne 24L For Sale
Melbourne 24L Description
Jayco Melbourne Class C diesel motorhome 24L highlights:
- 14' Power Awning with LED Lights
- Swivel Captain's Seats
- Full-Wall Slide
- Full Bath
- Pleated Blackout Shades
Head across the states in this comfortable coach that can sleep five each night. You will enjoy an RV queen bed just like you have at home, and your guests can sleep on the U-shaped dinette and cab-over bunk. If you're not needing the overhead bunk, just choose the optional front entertainment center with a 32" LED HDTV, and the dinette can also be optioned out for theater seating to make this a couples coach. You can prepare all your meals on the two burner drop-in cooktop, or use the convection microwave. The flip-up counter will provide more counter space, and all your perishables can be stored in the 10 cu. ft. 12V refrigerator.
Each Melbourne Class C diesel motorhome by Jayco features durable Stronghold VBL lamination, bead-foam insulation, and a seamless front cap that resists wear and tear from the elements. The 2L V4 twin turbo 211HP diesel engine with 332 ft. lb. torque will power your trips near and far, and the Mercedes-Benz chassis is ultra durable. There are seatbelts in all designated seating locations, and the captain's seats swivel around so they can become a part of the living area once parked. You'll appreciate the LP generator on board, as well as a 13,500 BTU A/C and a 30,000 BTU furnace to keep you comfortable year around. The interior of the Melbourne will have you feeling right at home with high-intensity LED lights, an 83" interior height with a padded vinyl ceiling, hardwood cabinet doors and drawers, and more!
Melbourne 24L Specifications
Sleeps | 5 |
Slides | 1 |
Length | 25 ft 2 in |
Ext Width | 8 ft |
Ext Height | 11 ft 5 in |
Int Height | 6 ft 11 in |
Interior Color | Ashbrook |
Exterior Color | Standard Graphics, Optional Partial Paint |
Hitch Weight | 5000 lbs |
GVWR | 11030 lbs |
Fresh Water Capacity | 43 gals |
Grey Water Capacity | 31 gals |
Black Water Capacity | 31 gals |
Tire Size | 215/85R16 |
Furnace BTU | 30000 btu |
Generator | LP |
Fuel Type | Diesel |
Engine | 2L V4 Twin Turbo Diesel |
Chassis | Mercedes-Benz 3500 |
Horsepower | 211 hp |
Fuel Capacity | 26 gals |
Wheelbase | 170 in |
Number Of Bunks | 1 |
Available Beds | RV Queen |
Torque | 332 ft-lb |
Refrigerator Type | 12V |
Refrigerator Size | 10 cu ft |
Convection Cooking | Yes |
Cooktop Burners | 2 |
Shower Size | 24" x 32" |
Number of Awnings | 1 |
LP Tank Capacity | 41 lbs |
Water Heater Capacity | 6 gal |
Water Heater Type | Gas/Electric |
AC BTU | 13500 btu |
Basement Storage | 17 cu. ft. |
TV Info | LR LED HD Smart TV |
Awning Info | 14' Electric w/LED Lights |
Gross Combined Weight | 15250 lbs |
Shower Type | Standard |
Electrical Service | 30 amp |
