New 2025 Prism Select 24FSS Motor Home Class C - Diesel

* The images displayed may represent all Prism Select models

Shop Prism Select 24FSS For Sale

Prism Select 24FSS Description

Coachmen Prism Select Class C diesel motorhome 24FSS highlights:

  • Full-Wall Slide
  • RV Queen Bed
  • 45" x 80" Bunk Over Cab
  • Large Bedroom Closet



With extra space from the full-wall slide, you'll love spending time in this Prism Select Class C diesel motorhome! You can bring along the whole gang because the RV queen bed, the dinette, and 45" x 80" bunk above the cab will provide plenty of sleeping space, and the ample storage will be very helpful for everyone's belongings. You can also stock up on some treats and goodies with the pantry slide out, and the full bathroom is a great convenience to have whenever you need to get cleaned up. Plus, there is an optional outside entertainment center that can be added and the dinette can be switched out for optional recliners!



There is much to love about each one of these Coachmen Prism Select Class C diesel motorhomes, starting with the Mercedes-Benz chassis that is sure to get you where you wish to go.  You will also appreciate the CrossFlex roof membrane which is a synthetic thermoplastic roof membrane that provides three times more puncture resistance than the competition. The Prism Select also comes with an American-made Azdel "SuperLite" substrate with aluminum framing to resist dry rot, and the 2" vacuum-bond laminated sidewalls are the thickest Azdel in its class. You will love the unique floorplan choices, thermofoil countertops, large closets, large sliding windows, and the Even Cool AC ducting system to keep you comfortable during the warm months. Come find your favorite one today!

Prism Select 24FSS Specifications

Sleeps 5
Slides 1
Length 24 ft 11 in
Ext Width 7 ft 8 in
Ext Height 10 ft 9 in
Int Height 6 ft 9 in
Hitch Weight 5000 lbs
GVWR 11030 lbs
Dry Weight 10232 lbs
Cargo Capacity 798 lbs
Fresh Water Capacity 35 gals
Grey Water Capacity 32 gals
Black Water Capacity 35 gals
Fuel Type Diesel
Engine V6 3.0L
Chassis 3500 Sprinter
Horsepower 188 hp
Fuel Capacity 24.5 gals
Wheelbase 170 in
Number Of Bunks 1
Available Beds RV Queen
Torque 325 ft-lb
Cooktop Burners 3
Number of Awnings 1
Axle Weight Front 4410 lbs
Axle Weight Rear 7720 lbs
LP Tank Capacity 85 lbs
Water Heater Capacity 6 gal
Basement Storage 37 cu. ft.
Awning Info 14' Armless with LED Light
Gross Combined Weight 15250 lbs
Shower Type Standard
